LA-T20
LA-T20

LA-T20

Dia 20mm,12mm/s speed,150N,with limited switch,customized

0.00
0.00

Product Description

Dia 20mm,12mm/s speed,150N,with limited switch,customized


Advantage
A waterproof tubular linear actuator is a type of linear actuator that is designed to be resistant to water and other liquids. It is commonly used in applications where the actuator may be exposed to moisture, such as outdoor or marine environments. Waterproof tubular linear actuators are typically sealed to prevent water ingress and damage to the internal components. They are often made with materials that are corrosion-resistant and can withstand exposure to water without compromising their performance. These actuators are suitable for use in various industries, including marine, automotive, and agricultural.

For full specifications,customization options,and dimension,please check linear actuator descripation or contact with our online engineer service.

Main technical data


ModelLA-T20
Input12V,24V,36V,48V DC
Load/Force/Thrust
Max 150N/15KG/33LBS,customized
Speed
Max 12mm/s,0.48inch/s,customized
StrokeMax 2000mm,80inch,customized
Limited switch
Build in,customized
Position signal feedbackHall sensor,customized
Duty cycle
25%
IP protection
IP65 IP66 or customized
Operation Temperature-25°C to 65°C (-13°F to 149°F)
Color
Silver
ControllerPower supply,wire or wireless switch,synchronous controller options
Mounting bracketStandard type or customized
CertificateCE,Rohs,ISO,UL


Gear Ration&Load&Speed&Current

Gear RationMax Force/Load NNoload speed MM/S 12V max current A24V max current ACustomized
A150N/15KG/33LBS30.60.3Yes
B120N/12KG/26.4LBS4.50.60.3Yes
C100N/10KG/22LBS60.60.3Yes
D50N/5KG/11LBS120.60.3Yes
